◆物料亮點 Product features
1. 開發有新意,外觀簡約時尚大方,環保型結果好;
2. 可以調節式漩風分離處理器,能將常用研磨材料與小焊接煙塵分離處理,好的研磨材料馬上運用;
3. 核心零器件應用高品質進口量所需要的零部件,的使用使用時間長;
4. 工藝工件的表明均勻的;
5. 多卡位裝修設計;工作員可直接工作噴砂。按照企業客戶需要,可供選擇擇手動操作時或主動 ;可按企業客戶標準要求制作廠!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆可用領域 Applicable scope
材料,手機金屬外殼,揚聲器開關面板,漢堡包烤盤等表面及方體工件的的噴砂加工工藝。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆主要是枝術參數指標 Main technical parameters
機器設備規格型號 Model |
STR-多工位輸送式噴砂機 |
整個機器長寬比 Complete machine size(mm) |
3000×1000×1700 |
上班空間區域 Work space(mm) |
2000×1000×800 |
外輸送機長寬高 Conveying the size(mm) |
500×1000×1000(2件) |
除灰箱的尺寸 Dedust box sizes(mm) |
600×600×1800 |
分割器電動機 Separator motor |
220V 50HZ 550W |
溶合器風口尺寸 Separator air volume |
8.5m3/min |
縮減氣流源 Compressed air source |
2-8bar(kg/cm2) |
噴槍 Spray gun |
2把 |
照明 Floodlight |
兩盞30W隔爆燈 |
系統質量 Machine weight |
550kg |
