本噴砂機適用于10-490mm口徑的多種零部件的上下外觀手工藝實際操作噴砂作業答案,清掉外外觀的黑垢、外觀去銹、外觀強化裝備、從而提高粗糙,度、除掉外觀剛度等。(舉列:電飯煲、杯具、不粘鍋、租賃機殼、租賃機殼、風扇葉片、木工鋸片的)可按顧客請求訂制單工序或雙工序。
The sandblasting machines apply to 10-490 mm diameter of of all kinds of the internal and external surfaces of the manual operation sandblast homework, remove the dirt, surface derusting appearance, surface strengthening and improving roughness, removing surface stress, etc. (for example: electric meal bao, cup with, titanium, cell phone casing, computer shell, impeller, saw blades, etc) make single or double position according to customers' special requirements.
◆首要技術工藝參數值 Main technical parameters
產品類型 Model |
STR-A1500型十三槍圓筒回升式 |
STR-A1600型八槍圓球傾動式 |
STR-A1600型十四槍園盤回升式 |
電腦整機尺寸 Complete machine size(mm) |
1500×2160×3000 |
1600×1800×2500 |
2200×2400×3000 |
工作的艙的尺寸 Working class size(mm) |
Φ1400 |
Φ1500 |
Φ2000 |
除塵設備箱外形尺寸 Dedust box sizes(mm) |
1000×1200×2500 |
1000×1200×2500 |
1400×1400×2500 |
小轉盤數 The small turntable for |
16個 |
8個 |
8個 |
噴槍數 Gun number |
12把 |
8把 |
14把 |
開關電源 Power |
380V相電壓電 |
380V三相四線電 |
380V三相四線電 |
照明 Floodlight |
2盞防暴燈 |
2盞隔爆燈 |
2盞防火燈 |
器機體積 Machine weight |
800kg |
750kg |
800kg |
